Custom Table and Fixturing System for Fence Manufacturing

Since 1994, CNT Motion Systems has been manufacturing machines for the fence industry. Our fence machines feature special air-activated, self-centering clamps to hold PVC, wood or aluminum fence posts ranging from 1-8" in width. The two-, four- and eight-spindled configurations deliver high production for this efficient, affordable solution.

CNT-950 Series Fence Machine available in:

• Four Aisles with Two Router Spindles
• Four Aisles with Four Router Spindles
• Eight Aisles with Four Router Spindles
• Eight Aisles with Eight Router Spindles

Features for Four Aisles with Two or Four Spindles

• Four 8" Wide X 144" Long Work Cells;
• Four Self-centering Aisles  with Hand Control Valves, 3/8" to 8" Clamp Range X 144" Long With PVC Feed Rollers;
• Four Pop-up Pins for Material End Stops with Hand Control Valves;
• 80" Wide X 172" Long Machine Footprint;
• AC Brushless Closed-loop Servo Drives;
• An IBM-compatible PC, State-of-the-art WinCNC™ Motion Control Software in a NEMA 12 Cabinet;
• A Full-perimeter Cable E-Stop;
• Computer Control Spindle On/Off;
• Pressurized and Lubricated 25mm Hiwin Bearing System;
• Two or Four Porter Cable Routers with Brackets;
• Microsystems Basic Fence Software.

Specifications Four Aisles with Two or Four Spindles
Repeatability.001"
Positioning Accuracy±.002"
Cutting AreaFour (8" X 144") Work Cells
Z-axis Travel11" *
Rapid Traverse X & Y1500 IPM
Rapid Traverse Z300 IPM
Drive MotorServo
Y-axis Drive SystemArmoloy Coated Helical Rack-and-pinion
X- & Z-axes Drive SystemHiwin Ball Screw
ControllerWindows® PC
Warranty1 Year
WeightApprox. 2500 Lbs.
Features for Eight Aisles with Four or Eight Spindles

• Eight 8" Wide X 144" Long Work Cells;
• Eight Self-centering Aisles with Hand Control Valves, 3/8" to 8" Clamp Range X 144" Long with PVC Feed Rollers;
• Eight Pop-up Pins for Material End Stops with Hand Control Valves;
• 105" Wide X 172" Long Machine Footprint;
• AC Brushless Closed-loop Servo Drives;
• An IBM-compatible PC, State-of-the-art WinCNC™ Motion Control Software in a NEMA 12 Cabinet;
• A Full-perimeter Cable E-Stop;
• Computer Control Spindle On/Off;
• Pressurized and Lubricated 25mm Hiwin Bearing System;
• Four or Eight Porter Cable Routers with Brackets;
• Microsystems Basic Fence Software.

Specifications for Eight Aisles with Four or Eight Spindles
Repeatability.001"
Positioning Accuracy±.002"
Cutting AreaEight (8" X 144") Work Cells
Z-axis Travel11" *
Rapid Traverse X & Y1500 IPM
Rapid Traverse Z300 IPM
Drive MotorServo
Y-axis Drive SystemArmoloy Coated Helical Rack-and-pinion
X- & Z-axes Drive SystemHiwin Ball Screw
ControllerWindows® PC
Warranty1 Year
WeightApprox. 3500 Lbs.

*Standard specs. Optional dimensions available. Call for details and pricing.
